| Model | Outside Dimensions(mm) | Hearth Dimensions(mm) | Power (kw) | Tempering Temperature ℃ | Rangfe Of Tempering time (min) | Diameter Of Tempered Pieces (mm) | Output Of Tempered Pieces (kg/h) | Weight Of Furnace Body (kg) | ||||
| Length | Width | heighe | Length | Width | heighe | |||||||
| YF 206 | 1600 | 750 | 1300 | 600 | 200 | 60 | 6 | Temperatu re in furnace may be freely adjusted and set within500℃ | 1.5-20 | 0.1-3 | 10-20 | 200 |
| YF 210 | 2000 | 750 | 1300 | 1000 | 200 | 90 | 8 | 2.5-40 | 0.1-6 | 18-25 | 250 | |
| YF 215 | 2600 | 750 | 1300 | 1500 | 200 | 90 | 12 | 4-50 | 0.1-6 | 25-35 | 350 | |
| YF 315 | 2600 | 850 | 1320 | 1500 | 300 | 90 | 16 | 4-50 | 0.1-6 | 35-50 | 750 | |
| YF 320 | 3300 | 850 | 1400 | 2000 | 300 | 90 | 20 | 6-60 | 0.1-6 | 50-70 | 950 | |
| YF 420 | 3300 | 950 | 1400 | 2000 | 400 | 90 | 26 | 6-60 | 0.5-6 | 60-80 | 1000 | |
| YF 425 | 3900 | 950 | 1400 | 2500 | 400 | 100 | 30 | 6-60 | 0.5-6 | 70-90 | 1200 | |
| YF 430 | 4400 | 950 | 1500 | 3000 | 400 | 100 | 35 | 8-60 | 0.5-6 | 80-120 | 1300 | |
| YF 440 | 6100 | 1050 | 1600 | 4000 | 400 | 120 | 52 | 12-60 | 1-12 | 130-180 | 2200 | |
| YF 520 | 4100 | 1100 | 1800 | 2000 | 500 | 100 | 35 | 8-50 | 0.5-10 | 80-100 | 1400 | |
| YF 530 | 5100 | 1100 | 1950 | 3000 | 500 | 120 | 45 | 10-60 | 0.5-10 | 150-180 | 1800 | |
| YF 540 | 6100 | 1100 | 1950 | 4000 | 500 | 130 | 60 | 12-60 | 1-14 | 200-250 | 2400 | |
| YF 550 | 7100 | 1100 | 1950 | 5000 | 500 | 130 | 75 | 14-90 | 1-16 | 250-300 | 2800 | |
| YF 560 | 8100 | 1100 | 1950 | 6000 | 500 | 150 | 90 | 14-90 | 1-16 | 300-500 | 3600 | |
| YF 590 | 11200 | 1100 | 1950 | 9000 | 500 | 200 | 135 | 30-180 | 1-18 | 800-1000 | 5000 | |
| YF 630 | 5100 | 1200 | 1950 | 3000 | 600 | 120 | 57 | 10-60 | 1-12 | 160-200 | 2200 | |
| YF 640 | 6100 | 1200 | 1950 | 4000 | 600 | 130 | 75 | 12-60 | 1-14 | 200-300 | 2600 | |
| YF 650 | 7100 | 1200 | 1950 | 5000 | 600 | 130 | 90 | 14-90 | 1-16 | 300-400 | 3200 | |
| YF 660 | 8100 | 1200 | 1950 | 6000 | 600 | 150 | 110 | 14-90 | 1-16 | 360-500 | 3800 | |
| YF 680 | 10100 | 1200 | 2000 | 8000 | 600 | 200 | 135 | 25-150 | 1-20 | 700-1100 | 5000 | |
| YF 690 | 11200 | 1200 | 2000 | 9000 | 600 | 220 | 150 | 30-180 | 1-20 | 800-1200 | 5500 | |
| YF 730 | 5100 | 1300 | 2000 | 3000 | 700 | 120 | 65 | 10-60 | 1-14 | 180-220 | 2500 | |
| YF 740 | 6100 | 1300 | 2000 | 4000 | 700 | 180 | 85 | 12-60 | 1-16 | 250-350 | 3200 | |
| YF 750 | 7100 | 1300 | 2000 | 5000 | 700 | 200 | 105 | 14-90 | 1-16 | 320-450 | 3500 | |
| YF 760 | 8100 | 1300 | 2000 | 6000 | 700 | 220 | 120 | 14-90 | 1-20 | 400-600 | 4300 | |
| YF 840 | 6100 | 1400 | 2000 | 4000 | 800 | 180 | 90 | 12-60 | 8-50 | 280-400 | 4000 | |
| YF 850 | 7100 | 1400 | 2000 | 5000 | 800 | 220 | 106 | 14-90 | 8-50 | 400-600 | 4600 | |
| YF 860 | 8100 | 1400 | 2000 | 6000 | 800 | 260 | 130 | 14-90 | 8-50 | 550-800 | 5200 | |
Production according to the customer's special requirements.
Customers need to choose the different models according to the quantity, diameter and required tempering time of the pieces to be treated
Heating tubes, instruments, alumina silicate refractory material are available.
