| Model | YF-CNC-8350 | |
| Diameter of the steel wire(mm) | Φ1.0-5.0mm（iron wire1.0-7.0mm） | |
| Input voltage | 380V±10%V50HZ (Customized) | |
| Max Wire Feed speed | Manɸ80m | |
| Max outer diameter of coiled spring | Manɸ80m | |
| Quantity of the wire feed wheels | 3 pairs | |
| Total power (kw) | 15.5 | |
| Number of axes | 3 axles | |
| Quantity of the wire feed wheelsel | 3 pairs | |
| Servo motor | Wire feeding | 7kw |
| mandrel rotate | 1.5kw | |
| Cam | 7kw | |
| Main Machine(L*W*H)(mm) | 1700*1300*2000 | |
| Net Weight of Machine (kg) | 1950 | |
1.Using Taiwan imported computer control system and servo motor.
2.The computer is in Chinses/English interface,easy to operation,accurate positioning,the computer can control 3-5 servo motors,
all can be synchronized or run separately.
3.The product has a precision detection tracking device,it can automatically shut down if find a substandard product.
4.The parameters such as outside diameter and angle can be modified at any moment according to the working status displayed on the screen.
5.The mechanical automatic lubricating oil supply design,to ensure the equipment movement for a long time.
After-Sales & Training
1. Our product is life-time warranty from B/L Date. Parts damaged during 12 months from B/L date will be replaced on the cost of the SELLER. But the carriage fee is borne by the buyer.
2. Seller provides the service for the buyer forever. Buyer can contact us by Skype, WhatsApp, Email and Telephone at any time. We provide 24h on-line service.
3. Buyer need mounting service and training abroad, all costs will be charged: visa, round flight tickets,boarding & lodging, labor charge of one engineer 150USD PER DAY.After receiving all the cost, seller willsend engineer to Buyer’s site.
4. Buyer need send 1-2 persons to Seller’s company for training. Training fee was borne by Seller. The flight ticket and the boarding & lodging expense should be borne by Buyer.
Products & Applications
The YF-CNC-8350 is a heavy-duty 3–5 axis cam-type CNC spring forming machine for spring steel wire from Ø1.0–5.0 mm and lower-strength mild steel wire up to Ø7.0 mm.
It is designed for efficient production of relatively standardized medium-heavy spring products using stable cam-driven forming movements.
Typical Manufacturable Products
• Medium-heavy torsion springs
• Standard double torsion springs
• Large extension springs
• Extension springs with standard hooks
• Agricultural return springs
• Industrial latch springs
• Garage hardware springs
• Furniture mechanism springs
• Heavy spring clips
• Large clothespin springs
• Industrial hook springs
• Door return springs
• Spring-loaded locking parts
• Standard torsion springs with formed legs
• Coiled spring components with basic bends
• Elastic retaining parts
• Heavy spring fasteners
• Standard custom cam-formed springs
Typical Industries
• Agricultural equipment
• Furniture hardware
• Garage and gate hardware
• Industrial machinery
• Door systems
• Fitness equipment
• General hardware
• Contract spring manufacturing
The YF-CNC-8350 is suitable for manufacturers requiring strong forming capability and economical production of standardized medium-heavy spring products.
