The YF-2D-4-60 is designed for high-efficiency production of wire products formed primarily within one plane.
Its four-axis CNC configuration provides accurate wire feeding, bending and cutting for components that do not require
repeated spatial rotation. This simpler forming architecture offers an economical solution for manufacturers producing flat
clips, hooks, pins and light industrial hardware.
The machine is particularly suited to electrical appliances, consumer products, display hardware, light machinery and
furniture accessories made from Ø2.0–6.0 mm wire.
| Model | YF-CNC-4-60 |
| Wire diameter | Φ2.0-6.0mm |
| Axles number | 4 axles |
| Wire Feed length | Infinite |
| Wire Feed speed | 100Meter/Mln |
| Wire Feed instruction value | ±0.01-±9999.99 |
| Input voltage | 380V±10%V50HZ (Customized) |
| Cam instruction value | ±0.1°- 359.9° |
| Wire feed shaft servo power | 2.9KW |
| Torsion shaft servo power | 1.0KW |
| Lifting platform servo power | 0.75KW |
| Cut shaft servo motor | 0.75KW |
| No. of wire feeding wheel | 3 pairs |
| Machine weight | 1200KG |
| Machine sizes | 2400x850x1650mm |
The YF-2D-4-60 is designed for producing two-dimensional wire products from Ø2.0–6.0 mm wire.
It is most suitable for products formed primarily within one plane, where production efficiency, dimensional consistency and fast program changeover are more important than complex spatial bending.
Flat retaining clips
Wire hooks
Small mounting brackets
Locking pins
R-shaped wire clips
Flat wire handles
Small support rods
Appliance wire components
Electrical fixing clips
Display hooks
Small rings and open loops
Custom planar wire forms
Electrical appliances
Consumer products
Display hardware
Light machinery
Furniture hardware
General metal components
Choose this model when the component is mainly planar. Products with repeated changes between different bending planes should be evaluated for a 5-axis or 7-axis machine instead.
