The YF-CNC-12100 is designed for manufacturers producing complex heavy-wire components from Ø4.0–10.0 mm wire. The following specifications summarize the key information required for
wire forming machine selection, including wire range, control configuration, forming capability, feeding structure, typical products and application industries.
| Selection Item | Specification |
|---|---|
| Machine Model | YF-CNC-12100 |
| Machine Category | Heavy-Duty CNC Wire Forming Machine |
| Applicable Wire Diameter | Ø4.0–10.0 mm |
| Control Configuration | 12-axis CNC servo control system |
| Wire Feeding System | Four pairs of wire feeding rollers |
| Forming Capability | Complex 2D and 3D heavy-wire components |
| Forming Functions | Wire feeding, wire rotation, multi-directional bending and coordinated slide forming |
| Typical Products | Heavy-duty hooks, structural brackets, industrial handles, support frames, protective wire guards, retaining components and custom formed wire parts |
| Typical Applications | Automotive components, commercial vehicle parts, furniture hardware, industrial equipment, retail fixtures and heavy-duty metal products |
| Suitable Production Type | Custom production, high-mix manufacturing, small-to-medium batches and repeat production |
| Tooling Support | Customized tooling can be developed according to customer drawings, samples and forming requirements |
| Machine Evaluation Requirements | Wire diameter, material grade, product drawing, dimensional tolerances, bending geometry and expected production output |
Machine selection should not be based on wire diameter alone. The final configuration must also consider the wire material, tensile strength, product dimensions, number of bends, bending directions,
three-dimensional geometry, forming tolerances and production speed requirements.
For an accurate machine recommendation, customers are advised to provide:
Product drawing or physical sample
Wire diameter and material grade
Overall product dimensions
Required dimensional tolerances
Estimated production quantity
Required cycle time or output
Special forming, cutting or tooling requirements
For complete servo motor configuration, installed power, machine dimensions, machine weight and standard equipment details, please refer to the full technical specifications of the YF-CNC-12100 CNC camless spring forming machine.
Intelligent CNC Control for Heavy Wire Forming
The YF-CNC-12100 combines coordinated 12-axis servo control with a heavy-duty wire feeding and forming structure. Operators can program wire feeding, wire rotation,
bending movements and forming sequences through the CNC control interface, enabling stable production of complex 2D and 3D heavy-wire components.
1.Coordinated 12-Axis Servo Control
The machine uses a coordinated 12-axis CNC servo control system to manage wire feeding, wire rotation, cutting and multiple forming movements. Each axis can operate
independently or work together according to the programmed forming sequence, providing the flexibility required for complex heavy-wire products.
2.Multilingual CNC Programming Interface
The CNC control system provides a clear and user-friendly multilingual interface for machine setup, program editing and production monitoring. Chinese and English interfaces
are available as standard, while additional languages can be customized according to customer requirements.
Operators can enter and adjust wire feeding lengths, bending angles, forming movements, production quantities and other process parameters directly through the controller,
helping simplify machine operation and operator training.
3.Real-Time Production Monitoring
The control system displays the operating status and programmed movements in real time. Depending on the selected configuration and inspection requirements, production
monitoring functions can help identify abnormal operating conditions and reduce the risk of producing non-conforming wire parts.
4.Flexible Parameter Adjustment
Wire feeding length, bending angle, forming position and other production parameters can be adjusted through the CNC interface. This allows operators to fine-tune the
forming process during machine setup, sample development and repeat production.
5.Automatic Lubrication Support
The machine is equipped with an automatic lubrication system designed to supply lubricant to key moving components. Regular lubrication helps reduce mechanical wear,
support smooth operation and improve long-term machine stability during continuous production.
Yinfeng provides comprehensive technical support throughout machine installation, commissioning and production. Our service team assists customers with machine setup,
operator training, CNC programming, tooling adjustment and production troubleshooting.
Remote Technical Support
Remote support is available through email, telephone, WhatsApp and video communication. Our engineers can assist with program adjustment, machine operation and forming-process optimization.
Installation and Commissioning
Detailed installation and commissioning guidance is provided with the machine. On-site installation and commissioning services can also be arranged according
to the customer's location and project requirements.
Operator and Programming Training
Training covers machine operation, CNC programming, tooling setup, parameter adjustment, routine maintenance and troubleshooting. Training can be provided at
the Yinfeng factory, remotely or at the customer's production site.
Custom Tooling and Sample Support
Forming tools and production solutions can be developed according to customer drawings, samples, wire materials and dimensional requirements.
Sample testing can be arranged before delivery when the required product information and material are available.
Spare Parts and Long-Term Technical Assistance
Yinfeng provides spare-parts support, maintenance guidance and long-term technical assistance throughout the service life of the machine.
Warranty terms and service scope are provided according to the confirmed machine configuration and sales contract.
The YF-CNC-12100 is designed for manufacturers producing large and complex 2D and 3D wire components from Ø4.0–10.0 mm wire. Its coordinated 12-axis CNC servo system supports wire feeding, wire rotation, cutting, multi-directional bending and complex forming sequences for heavy-duty wire products.
The machine is suitable for customized production, high-mix manufacturing, small-to-medium batches and repeat production across automotive, furniture, retail equipment, industrial hardware and heavy equipment applications.
The YF-CNC-12100 can be configured to manufacture a wide range of heavy-wire components, including:
Heavy-duty wire hooks
Structural wire brackets
Industrial handles
Support frames
Protective wire guards
Retaining components
Locking rods
Seat frame components
Headrest frame wires
Furniture frame parts
Shopping cart components
Heavy wire baskets
Display rack components
Shelf support wires
Heavy wire rings
Custom 2D wire forms
Complex 3D wire components
Final manufacturability depends on the wire material, tensile strength, product dimensions, bending radius, forming geometry, dimensional tolerances and required production output.
The YF-CNC-12100 is suitable for producing heavy-wire components used in automotive seating systems, commercial vehicles and structural assemblies.
Automotive seat frame components
Headrest frame wires
Locking rods
Retaining clips
Structural wire brackets
Support wires
Custom heavy-wire vehicle components
Its multi-axis forming capability supports products requiring long straight sections, multiple bending directions and complex three-dimensional geometries.
The machine can be used to produce heavy-wire frame components and formed hardware for sofas, chairs, beds, storage systems and commercial furniture.
Sofa frame components
Chair support wires
Bed frame wire parts
Connecting rods
Furniture brackets
Formed support components
Custom furniture hardware
Stored CNC programs help manufacturers achieve consistent repeat production across different furniture component designs.
The YF-CNC-12100 supports the production of heavy-wire components for shopping carts, display racks, storage systems and commercial retail fixtures.
Shopping cart components
Heavy wire baskets
Display rack frames
Product holders
Shelf support wires
Retail fixture components
Custom display hardware
The programmable forming system allows different product programs to be stored and recalled for flexible manufacturing.
The machine is designed for complex heavy-wire components used in industrial equipment, machinery protection, material handling systems and heavy-duty hardware.
Heavy-duty hooks
Industrial handles
Protective wire guards
Structural brackets
Support frames
Retaining components
Heavy wire rings
Custom 2D and 3D industrial wire forms
Its heavy-duty feeding and forming structure supports products requiring multiple coordinated bending and forming movements.
The coordinated servo axes enable the YF-CNC-12100 to complete wire feeding, wire rotation, cutting and multi-directional forming in a programmed sequence. This allows the machine to produce heavy-wire components that cannot be completed through simple single-plane bending.
Multi-directional wire bending
Wire rotation for three-dimensional geometries
Long straight-section feeding
Multiple bend angles in one program
Coordinated slide forming
Complex spatial wire geometries
Repeat production using stored CNC programs
Customized tooling for special wire components
The final forming process is developed according to the customer’s product drawing, wire material, number of bends, three-dimensional geometry, dimensional tolerance and production requirements.
The YF-CNC-12100 can be evaluated for processing different heavy-wire materials according to product geometry, wire strength and forming requirements.
Low-carbon steel wire
High-carbon steel wire
Stainless steel wire
Galvanized steel wire
Alloy steel wire
Other formable metal wire materials
The actual processing capability depends on wire tensile strength, hardness, surface condition, bending radius and product geometry. Customers should provide the wire specification, product drawing and required tolerances before final machine configuration.
Yinfeng can develop customized tooling and forming solutions according to customer drawings, physical samples, wire materials and production requirements.
For an accurate machine and tooling evaluation, customers are advised to provide:
Product drawing or physical sample
Wire diameter
Material grade
Tensile strength
Overall product dimensions
Required tolerances
Number and direction of bends
Estimated production quantity
Required cycle time
Special cutting or end-forming requirements
Sample forming tests can be arranged when the required product information and wire materials are available.
