| Model | YF-CNC-1225 | |
| Diameter of the steel wire(mm) | Φ0.4-2.5mm | |
| Max Wire Feed instruction value | 10000.00mm | |
| Min Wire Feed instruction value | 0.01mm | |
| ax Wire Feed speed | 0-100 m/min | |
| Max Wire Feed length | Infinite length | |
| Input voltage | 380V±10%V50HZ (Customized) | |
| Program data storage | More than 2000 pcs | |
| Total power (kw) | 12.9 | |
| Numberof axes | 12 axis | |
| Quantity of the wire feed wheels | 3 pairs | |
| Servo motor | Wire feeding | 2.7kw |
| WIre rotate | 2.7kw | |
| mandrel rotate | 0.75kw | |
| Spinner | 0.75kw | |
| Slide | 0.75kw*8 | |
| Main Machine(L*W*H)(mm) | 1450*1400*1650 | |
| Net Weight of Machine (kg) | 1500 | |
1.Using Taiwan imported computer control system and servo motor.
2.The computer is in Chinses/English interface,easy to operation,accurate positioning,the computer can control 10 -12 servo motors,all can be synchronized or run separately.
3.The product has a precision detection tracking device,it can automatically shut down if find a substandard product.
4.The parameters such as outside diameter and angle can be modified at any moment according to the working status displayed on the screen.
5.The mechanical automatic lubricating oil supply design,to ensure the equipment movement for a long time.
After-Sales & Training
1. Our product is life-time warranty from B/L Date. Parts damaged during 12 months from B/L date will be replaced on the cost of the SELLER. But the carriage fee is borne by the buyer.
2. Seller provides the service for the buyer forever. Buyer can contact us by Skype, WhatsApp, Email and Telephone at any time. We provide 24h on-line service.
3. Buyer need mounting service and training abroad, all costs will be charged: visa, round flight tickets,boarding & lodging, labor charge of one engineer 150USD PER DAY.After receiving all the cost, seller willsend engineer to Buyer’s site.
4. Buyer need send 1-2 persons to Seller’s company for training. Training fee was borne by Seller. The flight ticket and the boarding & lodging expense should be borne by Buyer.
Products & Applications
The YF-CNC-1225 is a high-flexibility multi-axis CNC wire forming machine for Ø0.4–2.5 mm wire. It is designed for manufacturers producing diversified small 2D and 3D wire components with multiple bends, changing forming directions and frequent product changeovers.
Typical Manufacturable Products
• Automotive electrical retaining clips
• Wiring harness clips
• Small cable-management components
• Electrical terminal supports
• Precision wire fasteners
• Small locking wire parts
• Miniature latch components
• Appliance mechanism linkages
• Small wire brackets
• Battery holder wire components
• Sensor mounting clips
• Lock mechanism wire parts
• Medical equipment retainers
• Precision wire loops
• Small wire eyelets
• R-clips and retaining pins
• Small custom hooks
• Electronic equipment support wires
• Fine 2D wire forms
• Complex 3D wire components
• Custom precision bent-wire products
2D and 3D Forming Capability
The multi-axis servo structure can coordinate wire feeding, wire rotation, cutting and several forming movements within one CNC program.
This enables the production of components with:
• Multiple bending planes
• Alternating bend directions
• Compact three-dimensional geometries
• Loops and retaining sections
• Short and long straight segments
• Offset bends
• Custom end geometries
• Small-radius curves
• Repeatable multi-step forming
Typical Industry Applications
Automotive Electrical Systems
Typical products include wiring clips, terminal supports, sensor retainers, cable-management parts and small locking components.
Electronics and Electrical Equipment
Typical products include contact supports, wire fasteners, retaining clips, equipment brackets and small conductive structures.
Medical and Precision Equipment
Typical products include formed-wire retainers, locating components, instrument supports and customized small wire parts.
Locks, Appliances and Consumer Products
Typical products include lock mechanism parts, appliance linkage wires, small hooks, retaining pins and mechanism clips.
Production Positioning
The YF-CNC-1225 is particularly suitable for high-mix manufacturing where different small wire products must be changed frequently without rebuilding a traditional mechanical cam system.
