| Model | YF-CNC-1240 | |
| Diameter of the steel wire(mm) | Φ1.0-4.0mm | |
| Max Wire Feed instruction value | 10000.00mm | |
| Min Wire Feed instruction value | 0.01mm | |
| Max Wire Feed speed | 0-100 m/min | |
| Max Wire Feed length | Infinite length | |
| Input voltage | 380V±10%V50HZ (Customized) | |
| Program data storage | More than 2000 pcs | |
| Total power (kw) | 18.5 | |
| Numberof axes | 12 axis | |
| Quantity of the wire feed wheels | 3 pairs | |
| Servo motor | Wire feeding | 5.5kw |
| WIre rotate | 1.2kw | |
| mandrel rotate | 1.2kw | |
| Spinner | 1.0kw | |
| Slide | 1.2kw*8 | |
| Main Machine(L*W*H)(mm) | 1450*1800*1900 | |
| Net Weight of Machine (kg) | 2800 | |
1.Using Taiwan imported computer control system and servo motor.
2.The computer is in Chinses/English interface,easy to operation,accurate positioning,the computer can control 12-15 servo motors,
all can be synchronized or run separately.
3.The product has a precision detection tracking device,it can automatically shut down if find a substandard product.
4.The parameters such as outside diameter and angle can be modified at any moment according to the working status displayed on the screen.
5.The mechanical automatic lubricating oil supply design,to ensure the equipment movement for a long time.
After-Sales & Training
1. Our product is life-time warranty from B/L Date. Parts damaged during 12 months from B/L date will be replaced on the cost of the SELLER. But the carriage fee is borne by the buyer.
2. Seller provides the service for the buyer forever. Buyer can contact us by Skype, WhatsApp, Email and Telephone at any time. We provide 24h on-line service.
3. Buyer need mounting service and training abroad, all costs will be charged: visa, round flight tickets,boarding & lodging, labor charge of one engineer 150USD PER DAY.After receiving all the cost, seller willsend engineer to Buyer’s site.
4. Buyer need send 1-2 persons to Seller’s company for training. Training fee was borne by Seller. The flight ticket and the boarding & lodging expense should be borne by Buyer.
Products & Applications
The YF-CNC-1240 is a versatile multi-axis CNC wire forming machine for Ø1.0–4.0 mm wire. It is designed for producing medium-size 2D and 3D wire components used in automotive systems, furniture hardware, appliances, architectural hardware and industrial equipment.
Typical Manufacturable Products
• Automotive seat retaining components
• Headrest support wire parts
• Door mechanism linkage wires
• Medium structural wire brackets
• Appliance support frames
• Furniture mounting components
• Hinge-related wire parts
• Industrial retaining clips
• Equipment locking components
• Wire safety pins
• Medium-duty wire hooks
• Tool-hanging wire parts
• Wire clamps
• Equipment positioning components
• Support loops
• Mounting wire frames
• Mechanical linkage rods
• Protective wire retainers
• Custom 2D wire forms
• Complex 3D industrial wire components
• Custom medium-wire parts
Industry Applications
Automotive Components
Typical products include seat-system wire parts, headrest supports, door mechanism components, retainers and fastening wires.
Furniture and Seating Hardware
Typical products include mounting brackets, connecting components, support wires, hinge parts and locking structures.
Appliances and Electrical Equipment
Typical products include internal support frames, linkage components, retaining parts, wire clamps and equipment brackets.
Architectural and Industrial Hardware
Typical products include safety pins, equipment retainers, mounting hooks, locating components and custom hardware wire forms.
Multi-Axis Forming Advantages
The coordinated multi-axis system allows several forming tools to approach the wire from different directions. This supports:
• Multi-plane bending
• Wire rotation
• Long feeding sections
• Alternating bend directions
• Complex hook and loop shapes
• Offset and stepped geometries
• Structural retaining features
• Repeat production using stored programs
The YF-CNC-1240 is positioned as a general-purpose model for customers requiring a broad balance between product size, forming complexity and production flexibility.
